Home > Stainless Steel 316/316L Angles
Stainless Steel 316/316L Angles are crafted for environments where strength, corrosion resistance, and long-term reliability are absolutely essential. Known for their excellent performance in harsh and chloride-rich conditions, these angles stand firm even when exposed to moisture, chemicals, and saltwater. Their refined balance of toughness and durability makes them a trusted structural element across industries that demand dependable performance. Whether used in marine frameworks, chemical plants, or heavy fabrication projects, SS 316/316L Angles offer unwavering stability. Their clean finish, high strength, and remarkable corrosion resistance make them a preferred choice for both structural and engineering applications.
SS 316/316L Angles feature chromium, nickel, and molybdenum, creating a powerful alloy known for its superior corrosion resistance. The lower carbon content in 316L enhances weldability without compromising strength. These angles offer high tensile strength, strong creep resistance, and excellent toughness even at extreme temperatures. They maintain stability under pressure, resisting pitting, cracking, and chemical attack. Designed to perform in chloride-heavy environments, SS 316/316L Angles deliver a perfect combination of durability, flexibility, and long-lasting mechanical integrity.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
We conducts a strict quality test and obtains certifications to guarantee the best Stainless Steel 316/316L Angles in terms of strength, corrosion resistance, and accuracy. Each product batch is certified for compliance with international standards and offers clients full assurance in terms of reliability, performance, and conformity to industrial needs for a variety of uses.
Stainless Steel 316/316L angles are L-shaped structural components known for their excellent corrosion resistance, strength, and durability. They are used in marine, chemical, and high-temperature applications for support and reinforcement.
Stainless Steel 316/316L equal angles have two legs of the same length, forming a 90-degree angle. They offer high strength and corrosion resistance, ideal for structural support in demanding environments.
Stainless Steel 316/316L unequal angles have legs of different lengths, creating a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L L angles are L-shaped structural components offering high strength, durability, and superior corrosion resistance. They are used for framing and support in marine, chemical, and high-temperature environments.
SS 316/316L T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are ideal for structural and framework applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L corner angles are L-shaped sections designed for reinforcing and joining corners. They offer high strength, durability, and excellent corrosion resistance, making them suitable for construction and architectural applications.
Stainless Steel 316/316L Angles are heavily used in industries that demand powerful corrosion resistance and structural strength. They are ideal for marine construction, offshore platforms, shipbuilding, and environments exposed to seawater. Chemical and pharmaceutical plants rely on these angles for support frames, equipment structures, and process machinery. Food processing units use them because they maintain hygiene and resist contaminants. They are also used in architectural projects, bridges, storage racks, and heavy fabrication works. From industrial frameworks to precision-engineered systems, SS 316/316L Angles deliver dependable performance that stays strong even under harsh working conditions.
