Ranya Stainless, a top-notch manufacturer and supplier based in Muscat, Oman, specializes in high-quality Stainless Steel Sanitary Tubing that meets the rigorous hygiene standards of today’s industries. Renowned for its precision, durability, and outstanding surface finish, their sanitary tubing guarantees contamination-free fluid handling in sensitive settings. Ranya Stainless is dedicated to providing products that adhere to international sanitary regulations, boasting excellent corrosion resistance, weldability, and smooth internal surfaces. With a strong focus on quality, reliability, and customer service, the company has built a solid reputation as a trusted supplier of Stainless Steel Sanitary Tubing across the food, beverage, pharmaceutical, and biotechnology sectors in Oman and beyond.
Stainless Steel Sanitary Tubing is primarily made up of iron, chromium, and nickel, with carefully measured amounts of carbon, manganese, and silicon to enhance corrosion resistance and structural integrity. It showcases impressive mechanical properties, including high tensile strength, good ductility, and exceptional toughness, making it durable in demanding hygienic conditions. The tubing features a sleek, polished interior surface that prevents bacterial growth and ensures smooth fluid flow. Its stability across various temperatures and compatibility with cleaning agents make it perfect for sanitary processing systems.
| ASTM | ASTM A270 / ASME SA 270 |
| Material | SS 304, SS 304L,SS 316,SS 316L |
| Outer Diameter | 1/2 Inch |
| Wall Thickness | 16 Gauge (0.065 Inch) |
| Length | 20 Feet |
| Finish | 20Ra Inner Diameter/ 32Ra Outer Diameter |
| Outer Diameter Tolerance | +/-0.005” / +/-0.13MM |
| Wall Thickness Tolerance | +/-10% |
| Length Tolerance | +1/8” / +3.18MM |
| Mill Test Certificate | EN10204 3.1 |
| Standard | 3A / ASTM A270 / A270M |
| Type | Seamless / Welded |
| Polish | Mechanical Polished / Electropolished |
| Certification | ASME BPE/ 3-A SSI |
| Grade | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Molybdenum |
| TP304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | |
| TP304L | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | |
| TP316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 |
| TP316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Temperure | Yield Strength | Heat | Tensile Strength | Elongation |
| Min. º F(º C) | Ksi (MPa), Min. | Treatment | Ksi (MPa), Min. | ||
| TP304 | 1900 (1040) | 30(205) | Solution | 75(515) | 35 |
| TP304L | 1900 (1040) | 25(170) | Solution | 70(485) | 35 |
| TP316 | 1900(1040) | 30(205) | Solution | 75(515) | 35 |
| TP316L | 1900(1040) | 25(170) | Solution | 70(485) | 35 |
Contact us to get a quick quote for your requirement.
We ensure absolute clarity and premium quality assurance with our Stainless Steel Sanitary Tubing. Every order is supported by comprehensive documentation, including a commercial invoice, packing list, fumigation certificate, heat treatment records, and NABL-certified lab test reports. In addition, we provide Material Test Certificates as per EN 10204/3.1b, PMI Test Reports, complete radiographic examination details, and Third-Party Inspection Certificates. Our structured documentation system is designed to deliver maximum transparency, client confidence, and satisfaction.
Stainless steel sanitary tubing is specially manufactured tubing designed for hygienic applications where cleanliness and corrosion resistance are critical, such as in food, beverage, pharmaceutical, and biotech industries.
The most common grades are 304/304L and 316/316L stainless steel. Grade 316L is preferred for its superior corrosion resistance, especially in applications involving harsh chemicals or saline environments.
It is widely used in dairy, brewery, winery, food processing, pharmaceutical manufacturing, biotechnology, and cosmetics industries, where sterile and contamination-free fluid transfer is essential.
Sanitary tubing usually complies with standards like ASTM A270, ASME BPE, and 3-A Sanitary Standards, ensuring smooth finishes, precise dimensions, and strict hygienic quality control.
This type of tubing is widely utilized in industries that demand strict hygiene, durability, and contamination-free fluid transfer. In the food and beverage industry, it’s essential for dairy processing, brewing, water filtration, and beverage production lines. The pharmaceutical and biotechnology sectors depend on it for sterile processing, drug manufacturing, and high-purity fluid systems. It’s also crucial in cosmetics production, medical equipment, and chemical handling, where cleanliness and corrosion resistance are vital. Additionally, sanitary tubing finds its place in cleanrooms, water treatment facilities, and high-tech manufacturing environments.
